| SYSTEM |
| IDIS Solution Suite | Compatible with Expert and Federation |
| Network Connection | 2 GbE RJ-45 Ports (1000Base-T) |
| Recording Data Rate | Up to 400Mbps |
| Number of Cameras | 64Ch Recommended |
| Hard Disk Drive Configuration | 8 SATA + 3 eSATA
RAID 1, 5, 10 Supported |
| SSD | 120G SSD for Operating System (M.2 type) |
| Operating System | Microsoft® Windows Embedded Standard 8 |
| Processor | Intel® I7-7700, 3.6GHz |
| Memory | DDR4 PC-17000, 16GB |
| Video Outputs | 1 HDMI, 1 DP, 1 VGA |
| USB | 6 ( 2 Front USB 2.0 + 2 Back USB 3.0 + 2 Back USB 2.0) |
| RS-232 | 1 (DB9) |
| MECHANICAL |
| Form Factor | 2U RACK Mount Chassis |
| Dimensions (W x D x H) | 482.6mm x 88mm x 523.5mm (19" x 3.5" x 20.6") |
| Weight | 12.6kg (27.8 lbs.) |
| ELECTRICAL |
| Power Input | AC 100-240V~, 50/60 Hz, 6.0 - 3.0A (Redundant) |
| Power Supply | Dual Power (REDUNDANT SMPS) |
| Power Consumption | 160W |
| ENVIRONMENTAL |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Operating Humidity | 0% to 90% |
| ACCESSORIES SUPPLIED |
| Power Cord | 1 |
| General |
| Certifications | FCC, CE, CB, UL, PSE |
Intelligent Codec
ONVIF
[VMS] IDIS Solution Suite
Extensible Interface
Easy Installation
Compatibility
